Unique pattern designed for great coverage optimal overlapping
Low overspray (bounce back)
Great transfer efficiency
Innovative High Efficiency (HE) advanced technology
QUICK THREAD TECHNOLOGY
1 Turn to lock/unlock the air cap
3 Turns to lock/unlock the fluid tip
Wide threads for easy cleaning
M16*P1.5 female thread fluid joint
Compatible with most traditional and disposable cup systems
Soft trigger pull to reduce fatigue
Precise lubricated adjustment knobs for better control
Innovative CNC machining to avoid the need for gaskets behind the fluid tip
Nozzle Size: 1.3mm
Cup Capacity: 600ml
Operation Pressure: 29psi
Weight: 0.7lbs. (325g)
Gun Dimensions W x H: 7" x 5-34" (175mm x 145mm)
Avgerage Air Consumption: 10.5 - 12.5cfm
Air Inlet Thread NPT: 1/4"
Required Compressor: 3 - 5hp
Maximun Pattern at 6" to 8" Distance: 11" - 13" (280-330mm)
Air Hose I.D. Size: 6 - 8mm
Return Policy *
Return for refund within: 30 days
Return for replacement within: 30 days
* Applies to purchases made on matcotools.com only; see your Matco distributor for warranty or return information on purchases made elsewhere.
Rated 4.5 out of 5 by 2
Rated 5 out of 5 by Harley This product spray very nice.
I have had this Matco Gun for 3 weeks now. Have sprayed a lot of new parts, and 2 all over paint jobs. Very impressed with this Gun. What I have learned to get the best results is, fluid control turned out 2.5 to 3 turns out. Lays down Base Coat and Clear very nice. Very little Orange Peel. Can't wait to get another one.
October 13, 2014
Rated 4 out of 5 by Ls1Na6c Easy to use and cleans up really well
Picked this 1.3 up from my sales guy and to be honest, it lays down material quite nicely.
It does really well with solid basecoats, even metallic bases, and I have even fed a couple of gallons of clear coat through it just for kicks. It lays down clear with very minimal orange peel, almost like glass.
Overall, it's a great gun for the price.
May 4, 2012
